AL01128 TOP WIND DROP LEG 3180 Kg

The AL01128 is a top wind landing leg featuring a 4 position drop leg.

Suitable for agricultural and industrial use.

PRODUCT SPECS

PRODUCT PHOTOS

Part NumberAL01128
Static load rating3180 Kg
Screw stroke. +_ 10mm400mm
Overall height closed610mm
Closed height to mount center.460mm
 Drop leg max extension 340mm  (4 x 85mm spacings)
Tube size diameter x shape65mm SQUARE
Unit weight11.25 Kg
FinishSilver Zinc Plated.
Mountweld on tube mount with pin.
